Product Details
Place of Origin: Henan, China
Brand Name: aobest
Certification: RoHS Reach Approval
Model Number: insulator
Payment & Shipping Terms
Minimum Order Quantity: 500 pieces
Price: $1.00 - $4.00/pieces
Packaging Details: wooden case or carton
Supply Ability: 200000 Piece/Pieces per Month
Type: |
Insulator |
Material: |
FiberGlass |
Application: |
High Voltage |
Rated Voltage: |
33kv |
Tensile Strength: |
132kn |
Product Name: |
Glass Insulator |
Standard: |
IEC61109 |
Packing: |
Pallet |
Port: |
Qingdao |
Type: |
Insulator |
Material: |
FiberGlass |
Application: |
High Voltage |
Rated Voltage: |
33kv |
Tensile Strength: |
132kn |
Product Name: |
Glass Insulator |
Standard: |
IEC61109 |
Packing: |
Pallet |
Port: |
Qingdao |
High Strength insulator, Competitive Price, Good Technical Service, Delivery Goods on Time, Stable Quality, Great Performance
| Type | 52-3 | ||||
| Main Dimensions(mm) | D | 254 | |||
| H | 146 | ||||
| Creepage Distance | 292 | ||||
| Power-frequency Puncture Voltage(kv) | 110 | ||||
| Average flashover voltage | Power-frequency | Dry(kv) | 80 | ||
| Wet(kv) | 50 | ||||
| Critical-Impulse 1540us wave | Positive(kv) | 125 | |||
| Negative(kv) | 130 | ||||
| Radio-Influence-voltage Data | Test Voltage to ground(kv) | 10 | |||
| Maximum RIV at 1000kHz(uV) | 50 | ||||
| Electromechanical Failing Load(KN) | 67 | ||||
| Mechanical Impact Strength(n.m) | 5.5 | ||||
| Time Load Test Value(kn) | 44 | ||||
