Product Details
Place of Origin: Henan, China
Brand Name: Aobest
Certification: ISO9001/ISO14001 /OHSAS18001/CCC
Model Number: U1007 1672 U 1855
Payment & Shipping Terms
Minimum Order Quantity: 10 meters
Price: $0.10 - $9.00/meters
Type: |
Insulated |
Application: |
Heating |
Conductor Material: |
Copper |
Conductor Type: |
Solid Or Stranded |
Insulation Material: |
PVC |
Color: |
Various |
Standard: |
IEC NEMA GB JIS |
Packing: |
100/200/305/500Meter |
Type: |
Insulated |
Application: |
Heating |
Conductor Material: |
Copper |
Conductor Type: |
Solid Or Stranded |
Insulation Material: |
PVC |
Color: |
Various |
Standard: |
IEC NEMA GB JIS |
Packing: |
100/200/305/500Meter |
Hook Up Wire U Style 1007/ 1672 / 1855
Plain annealed stranded copper phase conductor,
XLPE insulated surrounded by a concentric layer of plain annealed solid copper neutral conductors.
XLPE insulated and plain annealed solid strand bare copper earth conductors,
PVC outer sheath. Black.
600/1000 volts
grade to BS7870.
Choose a cable type
| CCC Code | Conductor size (MM2) | Stranding | Cores | Weight (KG/KM) | Overall Diameter (MM) | Gland Size | Cleat | Trefoil Cleat |
|---|---|---|---|---|---|---|---|---|
| 4SPLITCON | 4 | 7/0.85 | 1 | 206 | 9.6 | 20S | - | - |
| 6SPLITCON | 6 | 7/1.04 | 1 | 281 | 11.4 | 20 | - | - |
| 10SPLITCON | 10 | 7/1.35 | 1 | 394 | 12.7 | 20 | - | - |
| 16SPLITCON | 16 | 7/1.70 | 1 | 583 | 14.6 | 25 | - | - |
| 25SPLITCON | 25 | *7/2.14 | 1 | 843 | 18.7 | 32 | - | - |
| 35SPLITCON | 35 | 7/2.52 | 1 | 1300 | 23 | 40 | - | - |
Conductor identification :
Brown live/Blue neutral.
Should not be installed at temperatures below 0oc or above + 60oc.
Also available in Violet outer sheath in 6mm, 10mm, 16mm & 25mm.
* Stranding of neutral is the same as phase conductor except 25 sq mm which has 11 x 1.70mm.
Please contact me freely; maybe I’ll give you a big surprise. ^.^
